Cable Drum Screw Jack

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

We are the prime and distinct organization, engaged in manufacturing and supplying supreme quality Cable Drum Screw Jack. Manufactured under the guidance of our deft experts by utilizing best grade materials and advanced techniques, offered jack can be availed from us in multiple sizes and other specific options. Our quality analysts check this Cable Drum Screw Jack on diverse quality parameters before delivery at customer’s end.

Cable Drum Screw Jack are lighter in weight and indispensable for being used in the cable yard. Being versatile in nature, our vended jack can be adjusted within seconds due to their simple to use operations. The mentioned screw jack has been tested using DP, UV and load testing techniques for ensuring better and reliable performance. This Cable Drum Jack has been fabricated using stainless steel for withstanding diverse temperature like temperature, rainfall and many more. The base plate of our offered jack is ruggedly engineered for rendering stability even on the soft ground. Paint finish to offer the modular look.

Few Words of Caution :

While handling, appropriate PPE should always be worn
Cable drums are to be pushed into the travel direction
Use approved components to handle cable drums
Careful with the projecting nails available in the drums

Specification :

Technical Specifications
Model No	Cap. In. Ton	Min.Ht. In.mm.	Max. Height in.mm	Lift in.mm.	Screw Dia. in. Mm	Dia of holding shaft in mm	Base size
CDR-3	3	450	700	250	45	60	7"x14"
CDR-5	5	500	825	325	50	60	8"x16"
CDR-10	10	625	1075	450	55	75	9"x18"
CDR-15	15	725	1225	500	62	87	9"x20"
CDR-20	20	725	1225	500	70	100	9"x20"
CDR-25	25	800	1300	500	74	100	10"x22"
CDR-50	50	800	1300	500	100	120	12"x30"
