Low Height Jack

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

Owing to their fire resistance and longer life, this Low Height Jack is widely used in various electrical equipments. This is designed and constructed to lift loads that are at lower levels or applying forces. With our in-depth expertise and sound infrastructural base, we offer world jack that is highly demanded due to its salient features given below. Offered jack is manufactured under the vigilance of deft professionals, who make sure to utilize optimum quality materials and advanced machines. Moreover, we provide Low Height Jacks at reasonable prices with no hassle.

Application Areas:

Ship building or offshore industries
Heavy engineering & process industries
Power plants
Construction industries
Cement industries
Mining industries
Railways
Wind mill
Steel plants

Technical Details:

Capacity	Stroke	Model	Effective Area	Oil Cap.	Closed Height	Cylinder OD.	Bore Dia.	Ram Dia.	Saddle Dia.	Weight (Approx.)
Tons (kN)	(mm)	MT	cm. sq.	(cc)	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	(kg)
10 (111)	30	RCCS 10-30	15.9	48	90	70	45	35	NA	2.3
20 (218)	50	RCCS 20-50	31.2	160	115	90	63	50	NA	4.9
30 (309)	50	RCCS 30-50	44.2	221	120	100	75	60	NA	6
50 (550)	60	RCCS 50-60	78.5	471	125	130	100	80	60	11
75 (792)	60	RCCS 75-60	113.1	679	145	155	120	95	70	18.4
100 (1077)	60	RCCS 100-60	153.9	925	150	180	140	110	80	23.6
150 (1589)	60	RCCS 150-60	227	1362	165	220	170	140	100	43
200 (1985)	60	RCCS 200-60	314.2	1885	200	255	200	160	110	66
