From our extensive range of plate making products, we manufacture and supply supreme quality Self Propelled Electric Scissor Lift. Widely used for lifting horizontal shaped material, this lift is widely admired due to its in shipping, warehouses, logistic, packaging and various industries. For the manufacturing of this lift, our experienced and diligent professionals use premium grade materials that are procured from the reliable vendors of the market. Having a capacity of 1000kg, this Self Propelled Electric Scissor Lift is available with a lift height of 150 mm/1600 mm and can be purchased at reasonable rates.
Functionality and applicability
Offered Self Propelled Electric Scissor Lifts stand as optimal industry solutions, employed for increasing the productivity of work-sites. Perfect for maneuvering in tight locations, the lifts are absolutely applicable for outdoor & indoor construction, installation and maintenance applications with stiff as well as level surfaces. Characterized by reduced noise levels, the products are provided with excellent capacity as well as maximal platform workspace. Provided Self Propelled Electric Scissor Lifts are functional as the access platforms as well as outstanding industry solutions for increased safety & productivity.
Technical Details:
| JCPT1912HD | JCPT2212HD | |
| S.W.L | 600kg | 450kg |
| S.W.L On Extension | 113kg | 113kg |
| Max. Occupants | 2 | 2 |
| Working Height | 19.00m | 22.00m |
| Platform Floor Height | 17.00m | 20.00m |
| Overall Length | 4.50m | 4.50m |
| Overall Width | 1.22m | 1.22m |
| Overall Height (UP) | 3.43m | 3.68m |
| Overall Height (Down) | 2.59m | 2.84m |
| Platform Size | 3.98m x 1.19m | 3.98m x 1.19m |
| Platform Extension Size | 1.50m | 1.50m |
| Ground Clearance (A) | 0.19m | 0.19m |
| Ground Clearance (B) | 0.025m | 0.025m |
| Wheel Base | 3.20m | 3.20m |
| Turning Radius | 0.3/3.84m | 0.3/3.64m |
| Drive/Lifting Motor | 48V/8kw | 48V/8kw |
| Travel Speed (UP) | 1.5km/h | 1.5km/h |
| Travel Speed (Down) | 0.15km/h | 0.15km/h |
| Up/Down Speed | 120/90 Sec | 120/90 Sec |
| Batteries | 48V/580Ah | 48V/580Ah |
| Integrated Charger | 48V/50A | 48V/50A |
| Gradeability | 25.00% | 25.00% |
| Maximum Working Slope | 1.5/0.3° | 1.5/0.3° |
| Tyres | 22X9-16 | 22X9-16 |
| Weight | 9025kg | 9755kg |
Price:
![]() |
