Traversing Screw Jack

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

Since our establishment in 1987, we are instrumental in offering our customers a comprehensive gamut of Traversing Screw Jack. This is easier to handle and easy to install into an application due to their light weight and reduced space requirements. Under the guidance of our team, this is precisely manufactured using pristine grade materials with the help of advanced technology. Moreover, this Traversing Screw Jack can be customized as per the information provided by our valuable customers.

Technical Specifications
Model No	Cap in. Ton	Min Ht. In mm.	Max Height in mm.	Lift in mm.	Screw dia in . Mm	Head dia in mm	Will Traver in mm
STR â€“ 3	3	500	725	225	42	63	175
STR â€“ 5	5	500	725	225	45	63	175
STR â€“ 8	8	500	725	225	50	63	175
STR â€“ 10	10	600	850	250	55	70	250
STR â€“ 15	15	650	950	300	63	85	300
STR â€“ 20	20	650	950	300	72	100	400
STR - 25	25	650	950	300	76	100	400
STR â€“ 30	30	700	1000	300	80	100	400
STR â€“ 35	35	700	1000	300	83	110	400
STR â€“ 40	40	700	1000	300	90	110	400
STR â€“ 50	50	750	1000	250	100	120	400
STR â€“ 75	75	750	1000	250	120	145	400
STR â€“ 100	100	750	1000	250	125	145	400
STR â€“ 150	150	750	1000	250	150	150	400
STR- 200	200	750	1000	250	170	170	400
