Electric Boom Lift
Product Details:
Product Description
Our expertise enables us to manufacture and supply a broad range of Electric Boom Lift that is extensively used in logistic, factories and other industrial areas. Provided lift facilitates easy handling of goods and can be took from one side to another with no hassle. Manufactured with the use of components and contemporary technology, our dexterous professionals precisely check this on different parameters. According to various requirements of our clients, we provide this Electric Boom Lift in different specific options as per their choice.
Applicability and efficiency
We deal in Electric Boom Lifts, which feature extended run time, increased up-time and enhanced productivity. These machines are particularly configured so so to complete all of the scheduled services. Proffered with a turntable rotation, tight turning radius, and boom function, these are appreciated for their light-weighted as well as compact boom structures. Well-suited for projects on sensitive floors, the lifts are offered with operational fluency and consistency. Offered with precision, the Electric Boom Lifts work as the aerial work platforms, where the utilization of the boom enable the users to range great spacings from the unit, as well as the increased vertical heights.
| Dimensions | A38E |
| Max. Working Height | 13.5m |
| Max. Platform Height | 11.5m |
| Max. Working Outreach | 6.1m |
| Clearance Height at Max. Outreach | 5.4m |
| Platform floor Size (Inside) (E X F) | 0.58m x 1.3m |
| Max. Platform Size (Outside) (G X H) | 1.0m x 1.32m |
| Overall Width (B) | 1.50m |
| Overall length (C) | 4.04m |
| Stowed Height (D) | 2.0m |
| Ground Clearance | 120mm |
| Performance | |
| Platform Capacity (SWL) | 215kg |
| Max. drive speed (stowed) | 4.0km/h |
| Max. drive speed (elevated) | 0.7km/h |
| Turret Rotations | 360° non-continuous |
| Riase/Lower Time | 83/68 Sec |
| Gradeability | 36.00% |
| Inside Turning Radius | 0.4m |
| Outside Turning Radius | 2.4m |
| Tyres | 22 x 9 16 non Marking |
| Controls | Smooth, One Hand Proportional Controls |
| Drive System | Direct Drive DC |
| Power | 8 X 6V, 210 Ah Batteries |
| Weight | 3770 Kg |
| Sr. No. | Standard Features |
| | |
| 1 | Proportional One-Hand Controls |
| 2 | Minimal Front boom overhang |
| 3 | Ultra-tight Inside turning radius |
| 4 | Power Line to platform (No Sockets) |
| 5 | Tilt Alarm and Cut Out |
| 6 | 2 Person + equipment Capacity indoors |
| 7 | 1 Person + equipments Capacity outdoors |
| 8 | Large , Two Person Platforms |
| 9 | Direct DC Drive Parallel wire wheel Motors |
| 10 | Non-Marking Tyres |
| 11 | Duplicate Boom Controls at Ground Level |
| 12 | CE Approved |
| Sr. No. | Options |
| 1 | Special Points Colors |
| 2 | Flashing Amber Beacon |
| 3 | Manual Platform Rotator |
| 4 | Environmental Green Oil |
