Inbuilt Hydraulic Puller

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

Becoming a leading manufacturer and supplier of industrial products, we are offering the best quality Inbuilt Hydraulic Puller. This is manufactured using high quality materials and pioneering techniques in compliance with defined industry norms. The offered puller is is extensively used for removing gears, bearings, and other press-fitted parts with speed and ease. Furthermore, this Inbuilt Hydraulic Puller is inspected on defined industry parameters by the adroit quality inspectors to eradicate all the flaws.

Technical Specifications:

Standard Jaw Puller (2/3 Jaws)
	Output (tons)	Reach (mm)	Spread (mm)	Stroke (mm)	Weight (kg)
K-6SD	4 Tons	165	30-200/260	55-105	7.2
K-6IN	6 Tons	165	30-200/260	82-130	7.5
K-6INL	6 Tons	195	30-200/300	82-180	8.1
K-6INB	6 Tons	165/195	30-200/300	82-180	9.5
K-8IN	8 Tons	210	30-250/355	82-160	8.6
K-8INL	8 Tons	240	30-300/380	82-240	9.7
K-8INB	8 Tons	210/240	30-300/380	82-240	11.7
K-10IN	15 Tons	240	50-280/380	82-180	11.7
K-10INL	15 Tons	320	50-350/410	82-280	27.1
K-10INB	15 Tons	240/320	50-350/410	82-280	30.1

Bearing Cup Puller
Model No.	Output (Tons)	Spread (mm)	Weight (kg)
K-22	15 Tons	35/140	5
K-22-1	4 Tons	10/01/80	0.8
K-22-2	8 Tons	15/90	1.6
K-22-3	12 Tons	20/115	2.8
K-22-4	15 Tons	35/225	5.6
K-22-5	20 Tons	40/300	15.1

Jaw Type Puller
Model No.	Output (Tons)	Reach (mm)	Spread (mm)	Stroke (mm)	Weight (kg)
K-6IN EXTRA	10 Tons	195	30-250/310	82-130	11.6
K-6INL EXTRA	10 Tons	250	30-280/340	82-180	16.7
K-6INB EXTRA	10 Tons	195/250	30-280/340	82-180	18.5
K-8 IN EXTRA	12 Tons	240	30-300/370	82-160	9.5
K-8INL EXTRA	12 Tons	280	30-330/400	82-240	18.5
K-8INB EXTRA	12 Tons	240/280	30-330/400	82-240	20.1
K-11 IN	20 Tons	275	50-360/430	82-180	23.7
K-11INL	20 Tons	330	50-380/450	82-280	28.2
K-11INB	20 Tons	275/330	50-380/450	82-280	46.3
K-12IN	25 Tons	315	50-410/480	110-220	35.6
K-12INL	25 Tons	380	50-440/540	110-330	37.8
K-12INB	25 Tons	315/380	50-440/540	110/330	46.3
K15IN	30 Tons	405	100-540/640	110-260	50
